Material：SCM435
■ℓ：11.5mm
| Item No. | List Price (￥) | Opposite side Dimension (mm) |
L (mm) |
H (mm) |
D1 (mm) |
D2 (mm) |
W (g) |
Inner box | JAN code |
|---|---|---|---|---|---|---|---|---|---|
| SS-306 | 850 | 6 | 26 | 3.5 | 9.9 | 17.3 | 20 | 5 | 782557 |
| SS-307 | 850 | 7 | 26 | 4 | 10.8 | 17.3 | 20 | 5 | 782632 |
| SS-308 | 850 | 8 | 26 | 5 | 12 | 17.3 | 22 | 5 | 782717 |
| SS-309 | 850 | 9 | 26 | 5 | 13.3 | 17.3 | 23 | 5 | 782984 |
| SS-310 | 850 | 10 | 26 | 6 | 14.5 | 17.3 | 24 | 5 | 783011 |
| SS-311 | 850 | 11 | 26 | 7 | 15.8 | 17.3 | 25 | 5 | 783288 |
| SS-312 | 900 | 12 | 26 | 8 | 16.8 | 17.3 | 25 | 5 | 783363 |
| SS-313 | 950 | 13 | 26 | 8 | 18 | 17 | 24 | 5 | 783448 |
| SS-314 | 950 | 14 | 27 | 10 | 19.5 | 18.5 | 31 | 5 | 783523 |
| SS-317 | 1,000 | 17 | 29 | 10 | 23.3 | 21.5 | 51 | 5 | 783790 |
| SS-319 | 1,050 | 19 | 30 | 12 | 25.8 | 23.5 | 63 | 5 | 783875 |
| SS-321 | 1,300 | 21 | 32 | 12 | 28 | 26 | 77 | 5 | 784179 |
| SS-322 | 1,300 | 22 | 32 | 14 | 29.5 | 26.5 | 82 | 5 | 783950 |
| SS-323 | 1,600 | 23 | 33 | 14 | 30.8 | 27.5 | 95 | 5 | 784094 |
■ℓ：16mm
| Item No. | List Price (￥) | Opposit side Dimension (mm) |
L (mm) |
H (mm) |
D1 (mm) |
D2 (mm) |
W (g) |
Inner Box | JANcode |
|---|---|---|---|---|---|---|---|---|---|
| SS-408 | 850 | 8 | 36 | 8 | 13.2 | 21 | 44 | 5 | 795021 |
| SS-410 | 850 | 10 | 37 | 9 | 15.3 | 21 | 45 | 5 | 795106 |
| SS-411 | 850 | 11 | 37 | 9.5 | 16.5 | 21 | 46 | 5 | 795298 |
| SS-412 | 850 | 12 | 37 | 10 | 17.8 | 21 | 47 | 5 | 795373 |
| SS-413 | 850 | 13 | 37 | 10.5 | 19 | 22 | 53 | 5 | 795458 |
| SS-414 | 850 | 14 | 37 | 11 | 20.3 | 22 | 56 | 5 | 795533 |
| SS-417 | 900 | 17 | 37 | 12.5 | 23 | 23 | 69 | 5 | 795618 |
| SS-419 | 1,050 | 19 | 38 | 14 | 25 | 25 | 89 | 5 | 795885 |
| SS-421 | 1,200 | 21 | 38 | 15.5 | 29 | 27 | 102 | 5 | 795960 |
| SS-422 | 1,200 | 22 | 40 | 16 | 30 | 28 | 113 | 5 | 796189 |
| SS-423 | 1,200 | 23 | 40 | 16.5 | 31.5 | 29 | 128 | 5 | 796264 |
| SS-424 | 1,250 | 24 | 42 | 17 | 32.8 | 30 | 140 | 5 | 796349 |
| SS-426 | 1,450 | 26 | 42 | 19 | 35 | 32 | 165 | 5 | 796424 |
| SS-427 | 1,550 | 27 | 43 | 19.5 | 36.5 | 33 | 182 | 5 | 796509 |
| SS-429 | 1,750 | 29 | 43 | 20.5 | 39 | 35 | 205 | 5 | 777409 |
| SS-430 | 1,800 | 30 | 46 | 22 | 40 | 36 | 222 | 5 | 777416 |
| SS-432 | 1,900 | 32 | 46 | 23 | 42.8 | 38 | 250 | 5 | 777423 |
※JAN codes are shown without Maker code（4975180).
※List Price is for each unit.
