Material：S55C ( Body ) / Cr-V ( Socket )
| Item No. | List Price （￥） |
Width Across Flats （mm） |
Length （mm） |
Weight （g） |
Inner Box | JAN Code |
|---|---|---|---|---|---|---|
| RM-17×19N-S | 5,000 | 17×19 | 310 | 470 | 6 pcs | 385246 |
| RM-17×21N-S | 4,550 | 17×21 | 310 | 470 | 6 pcs | 385253 |
| RM-19×21N-S | 5,250 | 19×21 | 310 | 470 | 6 pcs | 385260 |
| RM-19×24N-S | 5,800 | 19×24 | 310 | 475 | 6 pcs | 385239 |
| Item No. | Head Outside Diameter （mm） |
Socket Outside Diameter（mm） | Head Thickness （mm） |
Socket Length（mm） | Guaranteed Torque（N・m） | |||
|---|---|---|---|---|---|---|---|---|
| Small d1 | Large d2 | Small | Large | Small | Large | |||
| RM-17×19N-S | 41.0 | 23.5 | 26.0 | 18.0 | 16.0 | 16.0 | 308.9 | 367.7 |
| RM-17×21N-S | 41.0 | 23.5 | 28.5 | 18.0 | 16.0 | 16.0 | 308.9 | 426.6 |
| RM-19×21N-S | 41.0 | 26.0 | 28.5 | 18.0 | 16.0 | 16.0 | 367.7 | 426.6 |
| RM-19×24N-S | 41.0 | 26.0 | 33.5 | 18.0 | 16.0 | 16.0 | 367.7 | 426.6 |
*JAN Codes are shown by 6 digits numbers which removed maker code (4975180).
*The price is for each unit.
*The price is for each unit.
Use
- Suitable for assembling scaffold or concrete formwork.
- For scaffolders, farmers, and DIY.
Caution
- Adjust to the width across flats of object.
- DO NOT extend the handle by inserting a pipe.
- Please DO NOT use this item as a hammer.
- Connect to safety code for fall prevention to use at height.
- DO NOT use for purposes other than as hand tool.
