Material：Cr-V
| Item No. | JAN Code | List Price （￥） |
Range （mm） |
L （mm） |
Weight （ｇ） |
Inner Box |
|---|---|---|---|---|---|---|
| RW-8×10 | 396839 | 7,450 | 8×10 | 192 | 110 | 6 units |
| RW-10×12 | 395276 | 7,450 | 10×12 | 199 | 130 | 6 units |
| RW-10×13 | 396914 | 8,450 | 10×13 | 216 | 170 | 6 units |
| RW-11×13 | 396754 | 8,450 | 11×13 | 227 | 180 | 6 units |
| RW-12×14 | 395351 | 8,450 | 12×14 | 228 | 190 | 6 units |
| RW-13×17 | 395436 | 9,800 | 13×17 | 257 | 270 | 6 units |
| RW-17×19 | 395863 | 10,050 | 17×19 | 291 | 360 | 6 units |
| RW-19×21 | 396082 | 10,750 | 19×21 | 315 | 440 | 6 units |
| RW-19×22 | 396167 | 11,700 | 19×22 | 315 | 440 | 6 units |
| RW-22×24 | 396402 | 13,550 | 22×24 | 344 | 550 | 6 units |
| RW-24×27 | 396594 | 15,000 | 24×27 | 363 | 700 | 2 units |
| RW-24×30 | 396600 | 16,100 | 24×30 | 380 | 790 | 2 units |
| RW-30×32 | 396679 | 17,650 | 30×32 | 411 | 1,050 | 2 units |
| Item No. | Head Diameter（mm） | Head Thickness（mm） | Handle（mm） | Guaranteed Torque（N・m） | Package | |||
|---|---|---|---|---|---|---|---|---|
| Smaller | Bigger | Smaller | Bigger | Thickness | Smaller | Bigger | ||
| RW-8×10 | 22.0 | 22.0 | 10.6 | 10.6 | 5.0 | 39.2 | 68.6 | 255×63 |
| RW-10×12 | 22.0 | 26.0 | 10.6 | 11.6 | 5.0 | 68.6 | 137.7 | 255×63 |
| RW-10×13 | 22.0 | 30.0 | 10.6 | 12.6 | 5.5 | 68.6 | 156.9 | 285×63 |
| RW-11×13 | 24.0 | 30.0 | 11.6 | 12.6 | 5.5 | 117.7 | 156.9 | 285×63 |
| RW-12×14 | 26.0 | 30.0 | 11.6 | 12.6 | 5.5 | 137.7 | 176.5 | 280×65 |
| RW-13×17 | 30.0 | 35.0 | 12.6 | 14.6 | 6.0 | 156.9 | 308.9 | 310×70 |
| RW-17×19 | 35.0 | 38.0 | 14.6 | 15.6 | 6.5 | 308.9 | 367.7 | 350×75 |
| RW-19×21 | 38.0 | 42.0 | 15.6 | 16.6 | 7.0 | 367.7 | 426.6 | 365×80 |
| RW-19×22 | 38.0 | 42.0 | 15.6 | 16.6 | 7.0 | 367.7 | 456.0 | 365×80 |
| RW-22×24 | 42.0 | 46.0 | 16.6 | 17.6 | 8.0 | 456.0 | 514.8 | 400×80 |
| RW-24×27 | 46.0 | 50.0 | 17.6 | 17.6 | 9.0 | 514.8 | 598.2 | – |
| RW-24×30 | 46.0 | 55.0 | 17.6 | 19.6 | 8.6 | 514.8 | 671.8 | – |
| RW-30×32 | 55.0 | 57.0 | 19.6 | 19.6 | 10.5 | 671.8 | 720.8 | – |
*JAN Codes are shown by 6 digits numbers which removed as maker code (4975180).
*The price is for each unit.
Item No. RW-8×10 RW-10×12 RW-10×13 RW-11×13 RW-12×14 RW-13×17 RW-17×19 RW-19×21 RW-19×22 RW-22×24 RW-24×27 RW-24×30 RW-30×32RW-8×9 RW-8×9 RW-10×11 RW-8×10 RW-10×11 RW-10×12 RW-10×13 RW-11×13 RW-12×14 RW-13×17 RW-14×17 RW-14×17 RW-15×16 RW-15×16 RW-17×19 RW-17×21 RW-17×21 RW-19×21 RW-19×22 RW-21×23 RW-21×23 RW-21×26 RW-21×26 RW-22×24 RW-24×27 RW-24×30 RW-30×32
Use
- For attaching and detaching a bolt and nut for a machining, equipment, vehicle, and etc.
Caution
- Chose proper size which suits to the size of bolt and nut.
- DO NOT use this tool slant and shallowly to bolt and nut.
- DO NOT use for purposes other than as hand tool.
