T HANDLE HEX KEY

T HANDLE HEX KEY



  • Long hexagon part make works at narrow space easier.
  • Adopt the best special alloy steel. Assessed Non oxidizing heat treatment. Tough enough for final tightening.

Material:Special Alloy Steel

Item No. List Price
(¥)
Weight
(g)
Inner Box JAN code
TSW-15 2,350 46.5 6 946508
TSW-20 2,550 49.5 6 946607
TSW-25 3,000 71.5 6 946683
TSW-30 3,400 73.5 6 946720
TSW-40 3,950 165 6 946768
TSW-50 4,300 228.5 6 946805
TSW-60 4,900 302 6 946843
TSW-80 5,750 462 6 946881
TSW-100 6,600 663.5 6 946928
Item No. S
(mm)
L
(mm)
H
(mm)
TSW-15 1.5 175 60
TSW-20 2 190 70
TSW-25 2.5 200 80
TSW-30 3 205 90
TSW-40 4 225 105
TSW-50 5 250 125
TSW-60 6 270 150
TSW-80 8 290 175
TSW-100 10 310 200

※JAN Codes are shown with 6 digital numbers which removed maker code (4975180).
※List price is for each unit.
 Item No. TSW-15 TSW-20 TSW-25 TSW-30 TSW-40 TSW-50 TSW-60 TSW-80 TSW-100

Use

  • For detaching bolt with ring.

Caution

  • Use wrench which match to hex dimension.
  • Install till the end of hex ring. Use with pushing the tool.
  • DO NOT use twisted/split wrench.
  • To detach rusted bolts, it may need torque more than the ability of the wrench. Please stop using when you cannot remove the bolt easily.
